imageobject

imageobject — A wrapper for image data and its associated meta-information

Synopsis

Content Model

imageobject ::=

Sequence of:
- info? (db.titleforbidden.info)
- One of:
  - svg:*
  - imagedata

Attributes

Common attributes and common linking attributes.

Description

An ImageObject is a wrapper containing ImageData and its associated meta-information.

If the SVG Module is used, ImageObject can also contain the svg:svg element.

Processing expectations

May be formatted inline or as a displayed block, depending on context. It might not be rendered at all, depending on its placement within a MediaObject or InlineMediaObject and the constraints on the publishing system. For a more detailed description of the semantics involved, see MediaObject.

Parents

These elements contain imageobject: imageobjectco, inlinemediaobject, mediaobject.

Children

The following elements occur in imageobject: imagedata, info (db.titleforbidden.info), svg:*.

Examples

<article xmlns='http://docbook.org/ns/docbook'>
<title>Example imageobject</title>

<mediaobject>
  <imageobject>
    <imagedata fileref="figures/eiffeltower.eps" format="EPS"/>
  </imageobject>
  <imageobject>
    <imagedata fileref="figures/eiffeltower.png" format="PNG"/>
  </imageobject>
  <textobject>
    <phrase>The Eiffel Tower</phrase>
  </textobject>
  <!-- FIXME: get caption back -->
  <!-- <caption>
   <para>Designed by Gustave Eiffel in 1889, The Eiffel Tower is one of the
most widely recognized buildings in the world.
</para>
  </caption> -->
</mediaobject>

</article>

ChangeLog

This alpha reference page is $Revision: 1.5 $ published $Date: 2005/10/31 18:42:45 $.
